Effizient konstruieren mit Hilfe des Murtfeldt Kunststoffe CAD-Portal

Efficient design supported by the Murtfeldt CAD area

2D and 3D data on Murtfeldt products can be quickly and easily downloaded via the Murtfeldt CAD area. Instead of spending large amounts of time on their own drawings and designs, Murtfeldt customers can download the required data for chain, belt, and sliding guides as well as for tensioning systems with just a few clicks.

The area supports all prevalent CAD systems. The availability of CAD data is published on the Murtfeldt Website: Besides the product article number in the relevant product tables is a cube symbol which is linked to the Murtfeldt CAD area.

The procedure for selecting the required CAD data is optimally defined and simple:

  • In an initial step, the portal visitor selects the desired product group. He or she then clicks on the CAD button to display the product in detail.
  • Next, the customer selects 2D or 3D views or the configuration of the product from the provided menus.
  • The required data can be saved for download using the disk symbol.
  • Finally, the customer downloads the buffered data via the "Download Centre" menu.
